SKU 4295

《お取り寄せ商品》Romeo BLE - Arduino Robot Control Board with Bluetooth 4.0

送料区分: 650

商品コード: DFROBOT-DFR0305

発売日: 2018-11-21

短いURL: ssci.to/4295

この商品は取寄商品です

¥7,404 (税込)
¥7,404 - ¥7,404
Current price ¥7,404

本商品はお取り寄せ商品(輸入代行)です。他の商品と同時にご注文いただいた場合、全ての商品が入荷してから出荷します。お急ぎの商品と一緒にご注文なさらないよう、ご注意下さい。この商品のお買い求めの手続きを完了し、代金のお支払いをいただいてから、お取り寄せを行います(請求書払いのご契約をいただいている場合には、もちろんこの契約が優先です)。納期は仕入先に在庫がある場合、通常1.5~2ヶ月ほどです。発注は定期的に、まとめて行いますので、お取り寄せ依頼時に仕入先在庫があっても、当社発注時に仕入先在庫がない場合、納期は未定となります。

本商品は電気用品安全法、電波法、その他日本の法律に準拠していない可能性があります。本商品のお取り寄せは輸入代行サービスです。お取り寄せのご案内をご確認の上、ご注文ください。当社はお取り寄せ品に関して一切の責任を持ちません。お客様自身で適法かつ安全にご利用いただけることを充分にご確認いただき、お取り寄せをご依頼ください。また商品が輸入できないなどの問題が発生した場合、ご注文をキャンセルする場合があります。



Introduction

Romeo family is an All-in-One Arduino based control board especially designed for robotics applications from DFRobot. It benefits from the Arduino open source platform, it is supported by thousands of open source codes, and can easily be expanded with your Arduino shields. The integrated 2 way DC motor driver and wireless socket allows you to start your own robot project immediately without the need for an additional motor driver. Not just has the motor driver, Romeo is also designed to have extra power for servos which need more current.
Romeo is also featured with DFRobot's standard 3Pin-out designed and compatible with Gravity
series sensors and actuators. Hundreds of sensors are now plug-play with Romeo.
The Romeo BLE is a new member of Romeo Family. This robot controller inherits all functions of Romeo all-in-one controller, the Romeo BLE has integrated bluetooth 4.0, it is the first time to give a robot control board the power of easy set up. Thanks to the bluetooth 4.0, the Romeo BLE supports uploading sketch wireless which means you do not need to plug a cable to upload new code. Just need a USB Bluno Link adapter, the Romeo Ble is ready to be updated through the Air which is so convenient for robot application.
With Romeo BLE, all DFRobot's mobile platforms and robots can now be played with iOS devices by APP "GoBle". Also, the Romeo BLE supports Visual Programming APP (WhenDo).
What others say about this Romeo BLE?
"I have the Romeo BLE and consider it to be a huge step up from the standard Arduino boards I have. All those extra headers for the standard connections and the motor hookups make it a dream to work with." From Drew.

Specification

  • Microcontroller: ATmega328P
  • Bootloader: Arduino UNO
  • On-board BLE chip: TI CC2540
  • Transmission range: 70m in free space
  • Support bluetooth remote update the Arduino program
  • Support Bluetooth HID
  • Support iBeacons
  • Support AT command to config the BLE
  • Support Transparent communication through Serial
  • Support the master-salve machine switch
  • Support usb update BLE chip program
  • 14 Digital I/O ports
  • 6 PWM Outputs (Pin11, Pin10, Pin9, Pin6, Pin5, Pin3)
  • 8 10-bit analog input ports
  • 3 I2Cs
  • Two way H-bridged Motor Driver with 2A maximum current
  • 5 Buttons
  • Support Male and Female Pin Header
  • Integrated sockets for APC220 RF Module
  • Power Supply Port: USB or DC2.1
  • External Power Supply Range: 5-23V
  • DC output: 5V/3.3V
  • Auto sensing/switching external power input
  • Size: 94mm x 80mm(3.70"x3.15")

Documents

ShippingList

  • Romeo BLE (Arduino Compatible Atmega 328) x1



上記製品説明はDFRobotのサイトのHTMLをそのまま転載しております。当社サイトでの表示確認をしていないため表現が正しくない部分が残っております。また情報の更新が遅れている可能性もありますので、製品情報についてはDFRobot社のサイトをご確認ください。当社コード番号"DFROBOT-"以降のコードを製品検索に利用できます。たとえば、DFROBOT-DFR0470-ENTは、”DFR0470-ENT”とDFRobot社のサイトにて検索ください。



商品コード: DFROBOT-DFR0305
